15 Series Lockout L-O-X Valves Y1523C7012

  • Easily identifiable with a yellow body and a red handle to control ON/OFF positions (non-Stainless Steel)
  • Full size exhaust ports (equal to or larger than supply) provide rapid exhaust of downstream air and are threaded for silencers or remote exhaust lines
  • Design only allows the valve to be lockable in the OFF (closed) position
  • Fluorocarbon slipper seals for easy shifting, even after long periods of inactivity
  • Includes integrated sensing port for pressure verification with either a visual pop-up indicator or electrical pressure switch

Need Help? No Problem!

Customer Service

1-800-GET-ROSS

Technical Service
1-888-TEK-ROSS

Y1523C7012

$161.25

Quantity

Estimated Ship Date: 10/12/2023

*Estimated Ship Date based on standard manufacturing times for quantities of 10 or less. Shipments will be made anywhere in the United States.

Need Help? No Problem!

Customer Service

1-800-GET-ROSS

Technical Service
1-888-TEK-ROSS


Product Information

Actuation Manual
Function 3/2
Soft Start Not Included
Construction Spool
Thread Type NPT
Mounting In-line
Fluid Media Filtered Air
Operating Pressure 0 to 300 psig (0 to 20.7 bar)
Poppet/Spool Material Stainless Steel
Seal Material Fluorocarbon
Safety Category Category 1
DGUV Certification No
CE Certification No
EAC Declaration Yes
CSA/UL Certification No
Valve Body Material Cast Aluminum
Ambient Temperature 40 to 175 F (4 to 80 C)
Media Temperature 40 to 175 F (4 to 80 C)
PL Rating PL c
Series 15 Series Classic
Body Size 1"
Width 6.61 in (168 mm)
Exhaust Size 1-1/4"
Length 2.0 in (51 mm)
Height 8.96 in (228 mm)
Weight 2.0 lb (0.9 kg)
Inlet Size 1-1/4"
Outlet Size 1-1/4"
Cv (1-2) 7.1
Cv (2-3) 4.0
