Lever Valves 1123A2002
- Lever Valves
- Toggle Lever Valves
- Hand Lever Valves
1123A2002
$192.25
Quantity
Estimated Ship Date: 12/27/2025
*Estimated Ship Date based on standard manufacturing times for quantities of 10 or less. Shipments will be made anywhere in the United States.
Product Information
| Valve Type | Directional Control |
| Series | 11 |
| Application | General |
| Actuation | Manual Toggle Lever |
| Function | 3/2 |
| Default Position | Normally Closed |
| Return | Spring |
| Thread Type | NPT |
| Inlet Pipe Size | 1/4" |
| Outlet Pipe Size | 1/4" |
| Exhaust Pipe Size | 1/4" |
| Construction | Poppet |
| Mounting | Inline |
| Avg Cv | 0.5 |
| Ambient Temperature | -10 to 175 F (-23 to 80 C) |
| Media Temperature | -10 to 175 F (-23 to 80 C) |
| Fluid Media | Filtered Air |
| Operating Pressure | 5 to 150 psig (0.3 to 10 bar) |
| Length | 2.12 in (54 mm) |
| Width | 2.76 in (70 mm) |
| Height | 5.92 in (150 mm) |
| Weight | 1.0 lb (0.5 kg) |
| Valve Body Material | Cast Aluminum |
| Lever Position | Vertical |
+
Lever Valves
1123A2002
Contact Us for a 3D Model
+
Lever Valves
1123A2002
Contact ROSS Controls for Ordering Information
+
